Specifically the batch objects are:
● Batch types:
– Data types
– Units of measure
– Phase types
– Operation types
– Process tag types
– Equipment properties
● Batch instances:
– Process cell (folder)
– Units (folder)
– Equipment properties
– Equipment modules (EMOD) (folder)
– Neutral folder
– Equipment phases (EPH)
– Parameters of equipment phases
– Equipment operations (EOP)
– Parameters of equipment operations → currently selected object
– Process tags
– Process tag parameters
Runtime name in the dialog header
Display of the runtime name.
Process cell data
For navigation in the process cell data.
Properties
Name of the object selected in the navigation tree.
Description Any object description by the user.
Runtime name This consists of a prefix (symbolic computer name of the OS station) and
the path to the WinCC tag, separated by ::. Example: OS1_KH1D331::Proc‐
ess cell1/Unit1/CFC/EOPParameter
Name
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 1035
