Synchronization line
A synchronization line has been added.
The synchronization line was added. Three elements are connected to the synchronization
line in the "Recipe example - V2.0" recipe.
Property Value (left side) Value (right side)
Recipe_example_1
<Absolute path>
Recipe
Recipe Recipe example Recipe example
Version V1.0 V2.0
Last change 08.06.2015 14:36:58 (UTC
+2:00)
01.06.2015
11:06:05 (UTC
+2:00)
<Additional attributes> … …
Sync_13
<Absolute path>
Synchronization line
Comment
Number of connections 3
Synchronization point (node ID1) ROP_2 - ROP_5
Comment (node ID1)
Blocking (node ID1) Yes
Synchronization point (node ID2) ROP_4 - ROP_6
Comment (node ID2)
Blocking (node ID2) Yes
Synchronization point (node ID3) ROP_8 - ROP_9
Comment (node ID3)
Blocking (node ID3) Yes
The number of connections to the synchronization line has been changed.
The synchronization line was changed. Two elements are connected to the synchronization
line in the "Recipe example - V1.0" recipe and three elements in the "Recipe example - V2.0"
recipe.
Property Value (left side) Value (right side)
Recipe_example_1
<absolute path>
Recipe
Recipe Recipe example Recipe example
Version V1.0 V2.0
Last change 08.06.2015 14:36:58 (UTC
+2:00)
01.06.2015
11:06:05 (UTC
+2:00)
<Additional attributes> … …
BATCH Control Center
9.5 Recipes
SIMATIC BATCH V8.2
336 Operating Manual, 02/2016, A5E35958174-AA
