Property Value (left side) Value (right side)
Sync_14
<absolute path>
Synchronization line
Number of connections 2 3
Synchronization point (node ID) ROP_8 - ROP_9
Comment (node ID)
Blocking (node ID) Yes
A synchronization line with attributes has been added.
The added synchronization line is connected to two elements in the recipe and the following
attributes were allocated:
● Comment or description via "Properties" dialog of the synchronization line (SyncLine
comment)
● Comment or description specified via "Add comment" dialog for each of the two connection
points (SyncNode 2.1 Comment and SyncNode-2.2 Comment)
● The "Blocking" property was set to "No" at the connection point (NodeID2)
Property Value (left side) Value (right side)
Recipe_example_1
<Absolute path>
Recipe
Recipe Recipe example Recipe example
Version V1.0 V2.0
Last change 08.06.2015 14:36:58 (UTC
+2:00)
01.06.2015
11:06:05 (UTC
+2:00)
<Additional attributes> … …
Sync_15
<Absolute path>
Synchronization line
Comment SyncLine comment
Number of connections 2
Synchronization point (node ID1) ROP_2 - ROP_5
Comment (node ID1) SyncNode-2.1 Com‐
ment
Blocking (node ID1) Yes
Synchronization point (node ID2) ROP_4 - ROP_6
Comment (node ID2) SyncNode-2.2 Com‐
ment
Blocking (node ID2) No
Monitoring container
A monitoring container has been added.
BATCH Control Center
9.5 Recipes
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 337
