The monitoring container named "Monitoring" has been changed. Three elements will be
monitored with the monitoring container in the "Recipe example - V1.0" recipe and four
elements in the "Recipe example - V2.0" recipe.
Property Value (left side) Value (right side)
Recipe_example_1
<Absolute path>
Recipe
Recipe Recipe example Recipe example
Version V1.0 V2.0
Last change 08.06.2015 14:36:58 (UTC
+2:00)
01.06.2015 11:06:05
(UTC +2:00)
<Additional attributes> … …
Monitoring_8
<Absolute path>
Monitor
Number of monitored elements 3 4
Elements that were added in the monitored area
Recipe loop
A recipe loop has been added.
The recipe loop was added. The recipe loop contains two elements in the "Recipe example -
V2.0" recipe.
Property Value (left side) Value (right side)
Recipe_example_1
<Absolute path>
Recipe
Recipe Recipe example Recipe example
Version V1.0 V2.0
Last change 08.06.2015 14:36:58 (UTC
+2:00)
01.06.2015 11:06:05
(UTC +2:00)
<Additional attributes> … …
Loop_11
<Absolute path>
Loop
Comment Loop
Number of subelements 2
Elements that were integrated in the loop
The number of elements in the recipe loop has been changed.
BATCH Control Center
9.5 Recipes
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 339
