The recipe loop was changed. The recipe loop contains two elements in the "Recipe example
- V1.0" recipe and three elements in the "Recipe example - V2.0" recipe.
Property Value (left side) Value (right side)
Recipe example
<Absolute path>
Recipe
Recipe Recipe example Recipe example
Version V1.0 V2.0
Last change 08.06.2015 14:36:58 (UTC
+2:00)
01.06.2015 11:06:05
(UTC +2:00)
<Additional attributes> … …
Loop
<Absolute path>
Loop
Number of subelements 2 3
Elements that were added in the loop
Transition conditions
Condition 3 of a transition has been added.
A 3rd condition has been added to the transition "Trans_4. The name of the transition is located
in the absolute path. The condition itself is represented by the attributes.
The example corresponds to the condition:
U3_String value from RUP_2 unit must not have the value "ERROR"
Property Value (left side) Value (right side)
Recipe_example_1
<Absolute path>
Recipe
Recipe Recipe example Recipe example
Version V1.0 V2.0
Last change 08.06.2015 14:36:58 (UTC
+2:00)
01.06.2015 11:06:05
(UTC +2:00)
<Additional attributes> … …
Trans_4
<absolute path>
Transition
Number of conditions 2 3
Logic (C1 OR C2) (C1 OR C2 OR C3)
Condition_12
<Absolute path>
Condition
Description
Operator <>
Right value ERROR
Left value U3_String (RUP_2:Uni‐
tParameter)
Effective immediately (left) Yes
BATCH Control Center
9.5 Recipes
SIMATIC BATCH V8.2
340 Operating Manual, 02/2016, A5E35958174-AA
