Condition of a transition has been changed.
The operator and the right value have been changed in the 3rd condition of a transition
"Trans_4". The name of the transition is located in the absolute path.
Property Value (left side) Value (right side)
Recipe_example_1
<Absolute path>
Recipe
Recipe Recipe example Recipe example
Version V1.0 V2.0
Last change 08.06.2015 14:36:58 (UTC
+2:00)
01.06.2015 11:06:05
(UTC +2:00)
<Additional attributes> … …
Condition
<Absolute path>
Condition
Operator <> =
Left value ERROR NULL
ESIG (electronic signature)
Set check mark at global attribute "Activate".
An ESIG is displayed as inserted if the check mark is set at the global attribute "Activate" in
the property dialog of the corresponding object (recipe, recipe function, etc.) in the ESIG tab.
In addition, at least one ESIG must be configured.
Here is an example for a newly inserted ESIG for a recipe with all available recipe-specific
actions for which ESIGs are possible:
● Abort batch
● Resume batch
● Release batch
● …
● Unlock
Property Value (left side) Value (right side)
Recipe_example_1
<Absolute path>
Recipe
Recipe Recipe example Recipe example
Version V1.0 V2.0
Last change 08.06.2015 14:36:58 (UTC
+2:00)
01.06.2015 11:06:05
(UTC +2:00)
ESIG activated No Yes
<Additional attributes> … …
ESIG that are available for this recipe ESIG
Remove check mark at global attribute "Activate"
BATCH Control Center
9.5 Recipes
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 341
