Possible status (basic status) of recipe procedure elements (RPEs)
Status Value, deci‐
mal
Description
RPE_STATE_UNDEFINED 0 Undefined
RPE_STATE_EDITED 1 Edited
RPE_STATE_IDLE 2 Idle
RPE_STATE_STARTING 3 Starting
RPE_STATE_RUNNING 4 Running
RPE_STATE_READY 5 Ready to complete
RPE_STATE_COMPLETING 6 Completing
RPE_STATE_COMPLETED 7 Completed
RPE_STATE_CONTINUOUS 8 Continuous
RPE_STATE_ABORTED 9 Aborted
RPE_STATE_ABORTING 10 Aborting
RPE_STATE_STOPPED 11 Stopped
RPE_STATE_STOPPING 12 Stopping
RPE_STATE_HELD 13 Held
RPE_STATE_HOLDING 14 Holding
RPE_STATE_RESUMING 15 Resuming
RPE_STATE_PAUSED 16 Paused after step
RPE_STATE_PAUSING 17 Pausing after step
RPE_STATE_SOFT_STOPPED 18 Stopped except for continuous
RPE_STATE_SOFT_STOPPING 19 Stopping except for continuous
Note
If a unit recipe contains ROP steps or substructure steps in "continuous operation" state, the
Continuous symbol is always displayed in the control recipe view, regardless of the respective
basic status. The Continuous symbol is not displayed if a recipe phase was configured for
continuous operation but has not yet reached this status.
Possible expanded status of recipe procedure elements (RPEs)
Status Value, hexa‐
decimal
Value, decimal Description
RPE_EXSTATE_0 0x0 0 Initial value
RPE_EXSTATE_ERROR 0x1 1 Error
RPE_EXSTATE_FOCUS 0x2 2 Edit flag set
RPE_EXSTATE_CMD_PROCESSING 0x4 4 Command processing active
RPE_EXSTATE_BREAKPOINT 0x8 8 Breakpoint
RPE_EXSTATE_UNIT_ALLOCATING 0x10 16 Waiting for allocation of the unit
RPE_EXSTATE_UNIT_ALLOCATED 0x20 32 Unit allocated
BATCH Control Center
9.8 Batch control
SIMATIC BATCH V8.2
430 Operating Manual, 02/2016, A5E35958174-AA
