Status Value, hexa‐
decimal
Value, decimal Description
RPE_EXSTATE_EPE_ALLOCATING 0x40 64 Waiting for allocation of the
equipment phase or operation
RPE_EXSTATE_EPE_ALLOCATED 0x80 128 Equipment phase or operation
allocated
RPE_EXSTATE_SIGNATURE 0x100 256 Input of an electronic signature
required
RPE_EXSTATE_DIALOG 0x200 512 Operator dialog open
RPE_EXSTATE_WRITE_LOCK 0x400 1024 Write protection set
RPE_EXSTATE_START_LOCK 0x80 2048 Start lock set
RPE_EXSTATE_CONTINUOUS 0x1000 4096 Continuing
RPE_EXSTATE_HOOKED 0x2000 8192 Automatic run sequence inter‐
rupted. Recipe element is wait‐
ing for trigger (e.g.
Mes_Sync_Request)
RPE_EXSTATE_MANUAL 0x4000 16384 Manual service
RPE_EXSTATE_TIME_EXPIRED 0x8000 32768 Runtime exceeded
RPE_EXSTATE_CHILD_BLOCKING 0x0001000 65536 Lower-level object blocked
(held, aborted or stopped)
RPE_EXSTATE_CHILD_WAITING 0x0002000 131072 Lower-level object waiting
RPE_EXSTATE_CHILD_OPERATING 0x0004000 262144 Lower-level object waiting for
operator intervention
RPE_EXSTATE_CHILD_ERROR 0x0008000 524288 Lower-level object in Error sta‐
tus
RPE_EXSTATE_EQUIPMENT_ERROR 0x0010000 1048576 Error in the equipment proper‐
ties
RPE_EXSTATE_ALLOCATION_ERROR 0x0020000 2097152 Connection error during alloca‐
tion
RPE_EXSTATE_PAUSE 0x0040000 4194304 Held
BF_API_RPE_EXSTATE2_VIRTUALALLOC 0x0080000 8388608 Virtual allocation - the unit is
still allocated (flat recipe)
RPE_EXSTATE_UNIT_DIALOG 0x0100000 16777216 RUP dialog open
RPE_EXSTATE_CONNECTION_ERROR 0x0200000 33554432 Connection error
RPE_EXSTATE_WAITING 0x0400000 67108864 Object waiting
RPE_EXSTATE_WARNING 0x0800000 134217728 Warning, such as setpoint de‐
viation
RPE_EXSTATE_DEACTIVATED 0x2000000 536870912 Deactivated
RPE_EXSTATE_DELETED 0x4000000 1073741824 Object that was deleted during
an online structure change
BATCH Control Center
9.8 Batch control
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 431
