Editing level 1
Editing level 1 is intended for the Plant view in which the processes of several cells can be
synchronized. A recipe unit procedure (RUP) is made up of recipe operations (ROPs). To
structure the process, you can use double lines to synchronize. This allows you to synchronize
the timing of ROPs in different units.
Note
Free editing mode:
In this mode, you can use all the structure elements of editing level 2 at editing level 1 (parallel
ROPs, loops, transitions,...).
Since this mode does not correspond to the standard, this mode will not be described in any
greater detail. The way in which the structure elements function is the same at both editing
levels.
Editing level 2
Editing level 2 is used to create ROP sequences. An ROP sequence begins with a Start step.
The Start step is followed by a transition that defines the start conditions. Every ROP sequence
ends with an End step. A transition that defines the end condition precedes every end step.
BATCH Recipe Editor
10.3 Recipe topology
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 505
