Siemens SIMATIC BATCH User Manual

Implementation in the BATCH Recipe Editor






Legend for figure
1) Synchronization line between the recipe unit procedures (RUPs). In the figure, for example
buffer B202 and reactor R502.
2) First recipe unit procedure buffer B202 with the recipe operations xferIn and xferOut as
transfer operations.
3) Second recipe unit procedure reactor R502 with the recipe operations add water, xferIn,
temperature etc.
4) Third recipe unit procedure premixer P302 with the recipe operation xferOut.
BATCH Recipe Editor
10.3 Recipe topology
SIMATIC BATCH V8.2
506 Operating Manual, 02/2016, A5E35958174-AA
