Icon on toolbar or
shortcut menu
Command Meaning
Hide parameter The parameter lines for which the "Hide parameter" parameter
property is activated in the master recipe are displayed or hid‐
den.
Update Updates all data in the OS control.
SFC visualiza‐
tion: Overview
Opens the SFC overview window for the selected recipe
phase in the process picture workspace. This command is
only supported when using SFC types.
If the "Always display in faceplate" check box is enabled in the
SFC topology settings in the WinCC Explorer, the SFC visu‐
alization is always displayed with the SFC overview window
and SFC detail window.
SFC visualiza‐
tion: Pane
Opens the SFC detail window for the selected recipe phase
in the process picture workspace.
This command is only supported when using SFC types.
If the "Always display in faceplate" check box is enabled in the
SFC topology settings in the WinCC Explorer, the SFC visu‐
alization is always displayed with the SFC overview window
and SFC detail window.
Open with BCC Opens the batch shown in the OS control in the BATCH Con‐
trol Center.
Close The batch displayed in the control is closed; the control no
longer shows any data. You can display a new batch in the
control at any time.
View Opens a menu in which you can select a control recipe view.
The following views are available for selection:
● Overview
● Right
● Left
● Top
● Bottom
● Above
● Below
Add to favorites Adds the selected object to the favorites.
Removes the selected object from the favorites.
Jump to condition Jumps to the condition in the recipe.
Jump to recipe el‐
ement
Jumps to the recipe element.
Jump to parame‐
ter
Jumps to the parameter.
BATCH OS controls
11.3 Operations in process mode
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 617
