Image 11-3 Control recipe view shortcut menu
Focus on active batch element
In the figure below, the SIMATIC BATCH OS Control Properties for a simple linear control
recipe is displayed.
Simple linear control recipes consist of an RUP and do not include synchronization, a jump,
an alternative branch or parallel branch.
Autofocus is automatically activated for batches based on such control recipes.
BATCH OS controls
11.4 Applications in process mode
SIMATIC BATCH V8.2
640 Operating Manual, 02/2016, A5E35958174-AA
