Specifically the batch objects are:
● Batch types:
– Data types
– Units of measure
– Operation types > operation type > operation type parameters → currently selected
element, phase types, and process tag types.
By selecting the appropriate folder, you can create new operation types, phase types,
and process tag types; by selecting a created object, you can change its properties. The
order of type parameters can be changed in the process cell tree via drag & drop. When
SFC types of the EOP/EPH category are used, the batch types are only read and
displayed in this dialog box (read only). Any modifications must be made in the SFC
chart.
– Equipment properties
● Batch instances:
– Process cell (folder)
– Units (folder)
– Equipment properties
– Equipment modules (EMOD) (folder)
– Neutral folder
– Equipment phases (EPH)
– Parameters of equipment phases
– Equipment operations (EOP)
– Parameters of equipment operations
– Process tags
– Process tag parameters
Runtime name in the dialog header
Display of the runtime name.
Process cell data
For navigation in the process cell data.
Properties
Name of the object selected in the navigation tree.
Description Any object description by the user.
Data type Assign the desired data type to the operation type parameter here. All
standard data types and user data types are available for selection. You
must specify desired user data types beforehand under "Data types".
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 983
