Button: Data type Activating this button takes you to the appropriate batch data type. Use the
Back button on the batch data type to return to this point.
Assigned unit of measure Assign the physical unit of measure to the operation type parameter here.
You must specify desired units of measure beforehand under "Units of
measure".
Button: Unit of measure Activating this button takes you to the appropriate unit of measure. Use the
Back button on the unit of measure to return to this point.
Archive measured value An operation type parameter is selected here if a connection to a WinCC
process tag is to be established. This selection is the prerequisite for as‐
signing a type parameter to process tag archive tag. You make this assign‐
ment subsequently on the instance parameter of the appropriate phase
type.
Test manufacturing in‐
struction
An operation type parameter is selected here if it is to be provided in the
batch log for the manual check (manufacturing instruction).
Control strategy parame‐
ter
Select the option if the type parameter is to be a control strategy.
Button: Edit This button opens a subsequent dialog. You assign the setpoints of the
operation to the individual control strategies here.
Events log ID Here you can specify a value from 0 - 65535 that can be evaluated later in
a user batch log to allow filtering. Different values are permitted for setpoint
and process value. This means, for example, that you could filter according
to setpoints with setpoint ID ≤ 1000 AND setpoint ID ≥ 500 and for process
values with process value ID ≤ 2000. The user can specify how convenient
such a query is in his log software.
Created by Specification of the application that created the object, either SIMATIC
BATCH PCell Control Center or SIMATIC Manager:
● If a type object was created by SIMATIC Manager, additional subobjects
cannot be added, nor can the selected object be deleted or changed,
either via the PCC API or with the PCC configuration dialog.
● If an instance object was created by SIMATIC Manager, additional
subobjects can be added via the PCC API or with the PCC configuration
dialog. However, it is still not possible to delete or change the selected
object here.
Parameters
Buttons
Update All batch instances are adapted according to the batch types. This action
is always required if a change has been made to batch types of existing
batch instances (e.g., inserting a new parameter, changing the unit of
measure, etc.).
Delete The operation type parameters object can be deleted here. Deletion is only
possible if the selected object is not in use.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
984 Operating Manual, 02/2016, A5E35958174-AA
