Specifically the batch objects are:
● Batch types:
– Data types
– Units of measure
– Operation types, phase types > phase type >phase type parameters → currently selected
element, and process tag types.
By selecting the appropriate folder, you can create new operation types, phase types,
and process tag types; by selecting a created object, you can change its phase type
parameters.
– Equipment properties
Batch instances:
– Process cell (folder)
– Units (folder)
– Equipment properties
– Equipment modules (EMOD) (folder)
– Neutral folder
– Equipment phases (EPH)
– Parameters of equipment phases
– Equipment operations (EOP)
– Parameters of equipment operations
– Process tags
– Process tag parameters
Runtime name in the dialog header
Display of the runtime name.
Process cell data
For navigation in the process cell data.
Properties
Name of the object selected in the navigation tree.
Description Any object description by the user.
Data type Assign the desired data type to the phase type parameter here. All stand‐
ard data types and user data types are available for selection. You must
specify desired user data types beforehand under "Data types".
Button: Data type Activating this button takes you to the appropriate batch data type. Use
the Back button on the batch data type to return to this point.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
992 Operating Manual, 02/2016, A5E35958174-AA
