Assigned unit of measure Assign the physical unit of measure to the phase type parameter. You must
specify desired units of measure beforehand under "Units of measure".
Button: Unit of measure Activating this button takes you to the appropriate unit of measure. Use
the Back button on the unit of measure to return to this point.
Archive measured value A phase type parameter is selected here if a connection to a WinCC proc‐
ess tag is to be established. This selection is the prerequisite for assigning
a phase type parameter to process tag archive tag. You make this assign‐
ment subsequently on the instance parameter of the appropriate phase
type.
Test manufacturing in‐
struction
A phase type parameter is selected here if it is to be provided in the batch
log for the manual check (manufacturing instruction).
Events log ID Here you can specify a value from 0 - 65535 that can be evaluated later
in a user batch log to allow filtering. Different values are permitted for set‐
point and process value. This means, for example, that you could filter
according to setpoints with setpoint ID < 1000 AND setpoint ID ≥ 500 and
for process values with process value ID ≤ 2000. The user can specify how
convenient such a query is in his log software.
Created by Specification of the application that created the object, either SIMATIC
BATCH PCell Control Center or SIMATIC Manager:
● If a type object was created by SIMATIC Manager, additional
subobjects cannot be added, nor can the selected object be deleted
or changed, either via the PCC API or with the PCC configuration
dialog.
● If an instance object was created by SIMATIC Manager, additional
subobjects can be added via the PCC API or with the PCC
configuration dialog. However, it is still not possible to delete or change
the selected object here.
Parameters
Buttons
Update All batch instances are adapted according to the batch types. This action
is always required if a change has been made to batch types of existing
batch instances (e.g., inserting a new parameter, changing the unit of
measure, etc.).
Delete The phase type parameter object can be deleted here. Deletion is only
possible if the selected object is not in use.
Log
"Errors" display field The number of errors for the selected log is displayed.
"Warnings" display field The number of warnings for the selected log is displayed.
"Display" button The logging is activated with the "Display" button. The selected log is
generated as an XML file in the specified layout and displayed in In‐
ternet Explorer.
Select "Process cell" and click the "Display" button to show all process
cell errors or warnings. You can also right-click a selected object and
select the "Display log" function to display object-specific errors or
warnings.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 993
