STRASBAUGH, INC.
7AF SECS/GEM Interface Ver. 1.9 February 19, 2002 11-1
Strasbaugh Confidential
11-1
11. Appendix D -- SECSII Data Item Formats
The following is a description of how the various SECS2 Data type are implemented in the 7AF.
Data
Type:
A ASCII
B Binary
J JIS-8
I1, I2, I4, I8 Signed Integers
U1, U2, U4, U8 Unsigned Integers
F4, F8 Floating Point
BOOLEAN True/False
Name of Parameter Data Type Size Explanation
ABS B 1 ABS - Any Binary String
ACK5 B 1 Acknowledge Code
ACKC6 B 1 Acknowledge Code
ACKC7 B 1 Acknowledge Code
ACKC10 B 1 Acknowledge Code
ALCD B 1 Alarm Code Byte
ALED B 1 Alarm Enable/Disable
ALID U4 4 Alarm ID
ALTX A 1..40 Alarm Text
ASER U4 4 Alarm Serial Number
CCODE U2 2 Command Code = 0
CEED BOOLEAN 1 Collection Event Enable/Disable
CEID U4 4 Collection Event ID
CMDA B 1 Command Ack. Code
COMMACK B 1 Establish Communications Acknowledge
CPACK B 1 Command Parameter Acknowledge
CPNAME A 1..20 Command Parameter Name
CPVAL A 1..20 Command Parameter Value
DATAID U4 4 Data ID
DATALENGTH U4 4 Total bytes to be sent.
DRACK B 1 Define Report Acknowledge
DSID U4 4 Data Set ID
ECNAME A 1..30 Equipment Constant Name
EAC B 1 Equipment Acknowledge
ERACK B 1 Enable/Disable Event Report Acknowledge
ERRW7 A 1..100 Text String describing error found in process
program
FCNID U1 1 Message Function
GRANT B 1 Grant
GRANT6 B 1 Permission to send one byte
HCACK B 1 Host Command Ack. Code
LENGTH U2 2 Length of text
LRACK B 1 Acknowledge Code
MDLN A 6 Model Number
MHEAD B 10 Header of bad msg
OFLACK B 1 Acknowledge for Off-Line request
ONLACK B 1 Acknowledge Code for On-Line request
