132 Pamux User’s Guide
PAMUX CABLING AND TERMINATION
Table B-5: Regular and Jacketed Cable
Cable Type
Max.
Distance
Recommended
Terminator
Regular
(flat ribbon)
500 ft. TERM1
jacketed
(plastic jacket)
500 ft. TERM1
Note: The Jacketed ribbon cable is covered with a vinyl/plastic cover that is used simply to prevent
abrasion or mechanical damage to the cable. The vinyl/plastic cover does not provide any RFI/EMI
shielding.
Table B-6: Ground Planed and Jacketed Cable
Cable Type
Max.
Distance
Recommended
Terminator
Ground Planed 250 ft. TERM2
Jacketed and
Ground Planed
250 ft. TERM2
Note: The “Ground Planed ribbon cable” is also known as “Shielded ribbon cable.” The shielded cable is
used to prevent RFI/EMI problems.
Table B-7: Bundled or Rolled Cable
Cable Type
Max.
Distance
Recommended
Terminator
Bundled or
Rolled
N/A N/A
(Not recommended for use with
any Opto 22 products)
CONNECTORS
The connectors listed in Table B-5 will work with any of the ribbon cables above.
Table B-8: Pamux Connectors
Manufacturer
Connector
Part Number
3M 3425-7000
Circuit Assembly CA-50IDSB
SPECIFICATIONS
