130 Pamux User’s Guide
Table B-2: Pamux-Compatible I/O Modules (cont’d)
Module Type Description
Compatible
Racks
1
DA3 Analog Output 4 to 20 mA Standard Analog
DA3T Analog Output 4 to 20 mA
2
Standard Analog
DA4 Analog Output 0 to 5 VDC Standard Analog
DA4T Analog Output 0 to 5 VDC
2
Standard Analog
DA5 Analog Output 0 to 10 VDC Standard Analog
DA6 Analog Output -5 to +5 VDC Standard Analog
DA7 Analog Output -10 to +10 VDC Standard Analog
DA8 Analog Output 0 to 20 mA Standard Analog
1
Standard analog racks are the PB4AH, PB8AH, and PB16AH.
2
Transformer-isolated module.
PAMUX COMPATIBLE DIGITAL I/O MODULES
All 5-Volt logic I/O modules from the SNAP, G4, Classic, and QuadPak families are compatible with
Pamux digital brainboards.
CABLES AND CONNECTORS
CABLES
The Pamux bus connects to a host computer or other device via a 50-pin flat-ribbon cable. The
maximum length of the Pamux bus is 500 feet.
Opto 22 provides a number of pre-made cables for the Pamux system, as listed in Table B-3. Contact
Opto 22 Product Support at 800-835-6786 for more information.
