Atmospheric Pre-aligner Manual
4000-0015 Rev 1
13
Installing a Pre-aligner
This chapter gives instructions for installing a pre-aligner only. If you are
installing an integrated system, use the instructions from your Robot
Manual and any other component manuals to coordinate the installation of
all components.
To install a pre-aligner, you will:
• Unpack the pre-aligner and the controller
• Position the pre-aligner and controller
• Level the pre-aligner
• Connect the pre-aligner to the controller
• Connect the vacuum source to the pre-aligner
• Access a user interface (EQT or a Teach Pendant)
• Verify connections
• Teach and operate the pre-aligner
Unpacking
CAUTION: Do not handle a nickel-plated pre-aligner with bare
hands. Use clean latex barrier gloves or similar gloves.
Fingerprints will stain finish unless removed immediately with
Windex™.
1. Remove the pre-aligner from its shipping box. Remove the anti-static
plastic bag(s).
2. Remove the controller from the shipping box. Remove the anti-static
plastic bag.
3. Remove cables, floppy disk, and manuals from the shipping box.
