Pamux User’s Guide 125
SPECIFICATIONS
PAMUX PRODUCT SPECIFICATIONS
AC28 ADAPTER CARD
Description Pamux bus adapter card for the IBM PC/AT bus
Power requirements 5 VDC ±0.1 V @ 1.5 A
Operating temperature 0°C to 60°C
Relative humidity 0% to 95%, non-condensing
Connectors 50-pin male header connector
Range Up to 500 feet total length
AC36 ADAPTER CARD
Description Pamux bus adapter card for a TTL parallel port using the Intel
multibus port configuration.
Power requirements 5 VDC ±0.1 V @ 1 A
Operating temperature 0°C to 70°C
Relative humidity 0% to 95%, non-condensing
Connectors Two 50-pin male header connectors (accepts HH series ribbon cable)
Range Up to 500 feet total length
Configuration jumper Reset
