128 Pamux User’s Guide
PAMUX-COMPATIBLE I/O MOUNTING RACKS
Table B-1: Pamux-Compatible I/O Mounting Racks
Brain
Board
Compatibl-
e Racks
I/O that Can Be Used
B4
(digital)
G4PB32H 32 channels of single-point I/O
PB32HQ
8 channels of quad pak I/O
(four points per module)
B5
(digital)
G4PB8H 8 channels of single-point digital I/O
G4PB16H 16 channels of single-point digital I/O
G4PB16HC
16 channels of single-point digital I/O
G4PB16J/K
16 channels of integrated single-point
digital inputs
1
G4PB16L
16 channels of integrated single-point
digital outputs
1
PB4H 4 channels of single-point digital I/O
PB8H
8 channels of single-point digital I/O
PB16H 16 channels of single-point digital I/O
PB16HC
16 channels of single-point digital I/O
PB16J/K
16 channels of integrated single-point
digital inputs
1
PB16L
16 channels of integrated single-point
digital outputs
1
SNAPD4M 16 channels of SNAP digital I/O
B6
(analog)
PB4AH
4 channels of single-point analog I/O
PB8AH 8 channels of single-point analog I/O
PB16AH 16 channels of single-point analog I/O
1
Rack features built-in I/O and therefore does not accept I/O modules.
PAMUX-COMPATIBLE ANALOG I/O MODULES
Table B-2 on the following page lists all the analog I/O modules currently available for Pamux systems.
Please note that this list is subject to change. If you do not see a particular type of module, or if you
require further information on any module, contact Opto 22.
For the power requirements for analog modules used with B6 stations, refer to Table B-6 on page B-10.
