Pamux User’s Guide 129
Table B-2: Pamux-Compatible I/O Modules
Module Type Description
Compatible
Racks
1
AD2T Analog Input 0 to 20 mA
2
Standard Analog
AD3 Analog Input 4 to 20 mA Standard Analog
AD3T Analog Input 4 to 20 mA
2
Standard Analog
AD4 Analog Input ICTD Standard Analog
AD5 Analog Input Type J Thermocouple Standard Analog
AD5T Analog Input Type J Thermocouple
2
Standard Analog
AD6 Analog Input 0 to 5 VDC Standard Analog
AD6HS Analog Input 0 to 5 VDC High-Speed Standard Analog
AD6T Analog Input 0 to 5 VDC
2
Standard Analog
AD7 Analog Input 0 to 10 VDC Standard Analog
AD8 Analog Input Type K Thermocouple Standard Analog
AD8T Analog Input Type K Thermocouple
2
Standard Analog
AD9T Analog Input 0 to 50 mV
2
Standard Analog
AD10T2 Analog Input 100-Ohm RTD
2
Standard Analog
AD11 Analog Input -5 to +5 VDC Standard Analog
AD12 Analog Input -10 to +10 VDC Standard Analog
AD12T Analog Input -10 to +10 VDC
2
Standard Analog
AD13T Analog Input 0 to 100 mV
2
Standard Analog
AD14T Analog Input 10-Ohm RTD
2
Standard Analog
AD15T Analog Input 28 to 140 VDC
2
Standard Analog
AD16T Analog Input 0 to 5 Amp AC/DC
2
Standard Analog
AD17T Analog Input Type R/S Thermocouple
2
Standard Analog
AD18T Analog Input Type T Thermocouple
2
Standard Analog
AD19T Analog Input Type E Thermocouple
2
Standard Analog
AD20 Analog Input Rate Standard Analog
1
Standard analog racks are the PB4AH, PB8AH, and PB16AH.
2
Transformer-isolated module.
SPECIFICATIONS
