Pamux User’s Guide 137
AD8, AD8T TYPE K THERMOCOUPLE
TEMP = (VALUE% - A0) * A1 + A2
where A0, A1, and A2 depend on VALUE% and can be derived from the following table:
VALUE% A0 A1 A2 Temp Range (°C)
< 96 0 0.3167899 -99.6 < -70
96 to 198 95 0.2892961 -69.6 -70 to -40
199 to 348 198 0
.
2675585 -39.8 -39 to 0
349 to 578 348 0.2518454 0.3 1 to 58
579 to 909 578 0.2478090 57.9 59 to 140
910 to 1365 909 0.2541073 140.2 141 to 256
1366 to 1870 1365 0.2456905 256.2 257 to 380
1871 to 3084 1870 0.2405867 380.1 381 to 672
3085 to 3621 3084 0.2456271 671.8 673 to 804
3622 to 4095 3621 0.2532714 803.8 805 to 924
4096 to 4524 4095 0.2611331 924.0 925 to 1036
4525 to 4874 4524 0.2685714 1035.9 1037 to 1130
4875 to 5170 4874 0.2770270 1130.0 1131 to 1212
5171 to 5422 5170 0.2858277 1211.9 1213 to 1284
> 5422 5422 0.2959973 1283.9 > 1285
Accurate to ±0.4°C from -100°C to 1250°C.
AD10T2 100-OHM PLATINUM RTD
A 100-ohm platinum RTD (reference DIN 43 760, alpha = 0.00385) must be used with the AD10T2 for the
following conversion algorithms to be accurate.
VALUE% Formula
Temp Range
(°C)
< 2111
A = (VALUE% * 0.09474182) - 50
TEMP = A + (0.000156 * A
2
) - (0.0156 * A) - 1.11
-50 to 150
2111 < 4094
A = (VALUE% - 2111) * 0.1008065 - 100
TEMP = A + (0.000156 * A
2
) + 248.45
150 to 350
4095 < 6218
A = (VALUE% - 4095) * 0.1082863 - 115
TEMP = A + (0.00017 * A
2
) + 462.76
350 to 580
> 6218
A = (VALUE% - 6219) * 0.118525 - 13
TEMP = A + (0.000188 * A
2
) + 711.565
580 to 850
Accurate to ±0.15°C from -50°C to 580°C, to ±0.2°C from 580°C to 850°C.
TEMPERATURE CONVERSIONS ROUTINES
Updated: 11/10/98
