Operations and Maintenance Manual Physical Description
Version 1.2 - June 2004 3 - 9
Figure 3-2 Left Side View
9
6 (Door 12)
7 (Door 13)
8 (Door 14)
5
3
(Door 5)
4 (Door 7)
1 2
(Door 1)
(Door 2)
1 Door 1 (Send 1 Cassette)
2 Door 2 (Send 2 Cassette)
3 Door 5 (Left Operator Door)
4 Door 7 (Left Handling Service Door)
5 Monitor (Side View)
6 Door 12 (Left Top Grind Area Door)
7 Door 13 (Left Middle Grind Area Door)
8 Door 14 (Left Lower Grind Area Door)
9 Disconnect Enclosure (Side View)
