Operations and Maintenance Manual Operator Functions
Version 1.2 - June 2004 8 - 27
4. Main Machine
Circuit Breaker Move the Main Machine Circuit
Disconnect Switch Breaker Disconnect Switch lever, located at the
upper right rear of the machine, UP to its on
position.
The red indicator lamp on the control panel
should now be ON.
Operator Action Explanation/Screen Display
5. <Machine ON> Press the green <Machine ON> pushbutton,
located on the control panel.
The white indicator lamp on the control panel should now be ON,
signaling that all motors and the vacuum pump have the ability to be
turned on.
The Main Menu, shown below, should be displayed on the monitor after
a brief delay for system self-checking and the loading of software.
Note: The motors will be enabled only after other criteria (such as
homing) is met; the vacuum pump starts when an automatic
grind cycle begins.
