MOUNTING RACKS
CLASSIC G4
DIGITAL
Form 459-980518
DATA SHEET
page 2/3
Opto 22 • 43044 Business Park Drive • Temecula, CA 92590 • Phone: (909) 695-3000 • (800) 321-OPTO • Fax: (909) 695-3095 • www.opto22.com
Inside Sales: (800)452-OPTO • Product Support: (800) TEK-OPTO • (909) 695-3080 • Fax: (909) 695-3017 • E-mail: support@opto22.com • FaxBack: (800)474-OPTO
Connections
Specifications
Operating Temperature
0° to 70°C
95% humidity, non-condensing
Interface Connectors:
Field
Control
Power
Screw-type terminal strip accommodates up to 10 AWG wire
Boxed header accepts a PAMUX B4 brain board
Screw-type terminals accommodate up to 10 AWG wire
Communications Two 50-pin header on connectors for the PAMUX bus
