110 Pamux User’s Guide
Table 4-2: Pamux Internal Registers
Register Description Register Description
0 Analog Channel 0 (LSB) 23 Watchdog Channel 1 (MSB)
1 Analog Channel 0 (MSB 24 Watchdog Channel 2 (LSB)
2 Analog Channel 1 (LSB) 25 Watchdog Channel 2 (MSB)
3 Analog Channel 1 (MSB) 26 Watchdog Channel 3 (LSB)
4 Analog Channel 2 (LSB) 27 Watchdog Channel 3 (MSB)
5 Analog Channel 2 (MSB) 28 Watchdog Channel 4 (LSB)
6 Analog Channel 3 (LSB) 29 Watchdog Channel 4 (MSB)
7 Analog Channel 3 (MSB) 2A Watchdog Channel 5 (LSB)
8 Analog Channel 4 (LSB) 2B Watchdog Channel 5 (MSB)
9 Analog Channel 4 (MSB) 2C Watchdog Channel 6 (LSB)
A Analog Channel 5 (LSB) 2D Watchdog Channel 6 (MSB)
B Analog Channel 5 (MSB) 2E Watchdog Channel 7 (LSB)
C Analog Channel 6 (LSB) 2F Watchdog Channel 7 (MSB)
D Analog Channel 6 (MSB) 30 Watchdog Channel 8 (LSB)
E Analog Channel 7 (LSB) 31 Watchdog Channel 8 (MSB)
F Analog Channel 7 (MSB) 32 Watchdog Channel 9 (LSB)
10 Analog Channel 8 (LSB) 33 Watchdog Channel 9 (MSB)
11 Analog Channel 8 (MSB) 34 Watchdog Channel 10 (LSB)
12 Analog Channel 9 (LSB) 35 Watchdog Channel 10 (MSB)
13 Analog Channel 9 (MSB) 36 Watchdog Channel 11 (LSB)
14 Analog Channel 10 (LSB) 37 Watchdog Channel 11 (MSB)
15 Analog Channel 10 (MSB) 38 Watchdog Channel 12 (LSB)
16 Analog Channel 11 (LSB) 39 Watchdog Channel 12 (MSB)
17 Analog Channel 11 (MSB) 3A Watchdog Channel 13 (LSB)
18 Analog Channel 12 (LSB) 3B Watchdog Channel 13 (MSB)
19 Analog Channel 12 MSB) 3C Watchdog Channel 14 (LSB)
1A Analog Channel 13 (LSB) 3D Watchdog Channel 14 (MSB)
1B Analog Channel 13 MSB) 3E Watchdog Channel 15 (LSB)
1C Analog Channel 14 (LSB) 3F Watchdog Channel 15 (MSB)
1D Analog Channel 14 MSB) 7A Watchdog Timer (LSB)
1E Analog Channel 15 (LSB) 7B Watchdog Timer (MSB)
1F Analog Channel 15 (MSB) 7C Status Register
20 Watchdog Channel 0 (LSB) 7E
Configuration Byte
(Lower 8 Channels)
21 Watchdog Channel 0 (MSB) 7F
Configuration Byte
(Upper 8 Channels)
22 Watchdog Channel 1 (LSB) 82 Semaphore Register
MSB= Most significant byte LSB= Least significant byte
PROGRAMING WITHOUT THE PAMUX DRIVER
