134 Pamux User’s Guide
Table B-9: Current Requirements for Pamux-Compatible Analog Modules
Module Description
+15 VDC
Current (mA)
-15 VDC
Current (mA)
Input Modules
AD2T 0 to 20 mA 35 35
AD3 4 to 20 mA 3 7.5
AD3T 4 to 20 mA 35 35
AD4 ICTD 16 11
AD5 Type J Thermocouple 17 12
AD5T Type J Thermocouple 45 45
AD6 0 to 5 VDC 16 11
AD6HS 0 to 5 VDC High-Speed 16 11
AD6T 0 to 5 VDC 35 35
AD7 0 to 10 VDC 16 11
AD8 Type K Thermocouple 17 12
AD8T Type K Thermocouple 45 45
AD9T 0 to 50 mV 45 45
AD10T2 100-Ohm RTD 45 45
AD11 -5 to +5 VDC 12 8
AD12 -10 to +10 VDC 12 8
AD12T -10 to +10 VDC 35 35
AD13T 0 to 100 mV 45 45
AD15T 28 to 140 VDC 35 35
AD16T 0 to 5 Amps AC/DC 35 35
AD17T Type S Thermocouple 30 30
AD18T Type T Thermocouple 30 30
AD19T Type E Thermocouple 30 30
AD20 Rate 25 15
Output Modules
DA3 4 to 20 mA 16 1
DA4 0 to 5 VDC 17 1
DA4T 0 to 5 VDC 35 35
DA5 0 to 10 VDC 17 1
DA6 -5 to +5 VDC 17 1
DA7 -10 to +10 VDC 17 1
DA8 0 to 20 mA 20 10
