I/O MODULE
G4 DIGITAL
DC INPUT
Form 253-990215
DATA SHEET
page 2/4
Opto 22 • 43044 Business Park Drive • Temecula, CA 92590 • Phone: (909) 695-3000 • (800) 321-OPTO • Fax: (909) 695-3095 • Internet: www.opto22.com
Inside Sales: (800) 452-OPTO • Product Support: (800) TEK-OPTO • (909) 695-3080 • Fax: (909) 695-3017 • E-mail: support@opto22.com • FaxBack: (800) 474-OPTO
Specifications
Units G4IDC5 G4IDC5B G4IDC5D G4IDC5G
Input voltage range VDC
VAC
10-32
12-32
4-16
4-16
2.5-28
---
35-60
35-60
Key feature
---
Higher
speed
High
speed
---
Input current at maximum line mA 25 45 30 6
Isolation input-to-output V
rms
4,000 4,000 4,000 4,000
Turn-on time ms 5 0.05 1 10
Turn-off time ms 5 .1 1.5 10
Input allowed for off-state mA, V 1, 3 .7, 1 .2, 1 .7, 7
Nominal output supply voltage VDC 5 5 5 5
Output supply voltage range
VDC 4.5-6 4.5-6 4.5-6 4.5-6
Output supply current at
nominal logic voltage
mA 12 12 12 12
Input resistance
(R1 in schematic)
Ω 1.5K 300 900 10K
Control resistance
(R
C
in schematic)
Ω 220 220 470 220
Output voltage drop V @ 50 mA .4 .4 .4 .4
Output current (sinking) mA 50 50 50 50
Output leakage with no input µA @ 30 VDC 100 100 10 100
Transistor V breakdown 30 30 30 30
Temperature:
Operating
Storage
°C
°C
-30 to +70
-30 to +85
-30 to +70
-30 to +85
-30 to +70
-30 to +85
-30 to +70
-30 to +85
