Operations and Maintenance Manual Machine Setup
Version 1.2 - June 2004 9 - 29
USING THE WHEEL AND CHUCK RECIPES MENU
SUMMARY
The list below is a summary of the procedures needed to enter dressing and truing
recipe parameters. The sections following provide detailed steps for each.
1. Select the name of the recipe.
2. Enter the dress and true data.
3. Quit and save your changes.
STEP 1 - SELECT THE NAME OF THE RECIPE
To select the recipe name:
Operator Action Explanation/Screen Display
1. Select Recipe At the Wheel and Chuck Recipes menu, touch the "Select
Recipe" button to display the Select Recipe submenu.
2. Coarse Wheel Touch the name of the recipe (for example, "Coarse
Wheel") to select it.
3. Ok Touch the "Ok" button to confirm.
The parameters of the recipe you chose will now be
transferred from memory to the menu screen, and the
name of the recipe will be displayed at the top of the
menu.
