Strasbaugh nTellect (Model 7AF) Wafer Grinder
12 - 28 Version 1.2 - June 2004
INFORMATION AND CHOICES AVAILABLE AT THE MACHINE SETUP ENTRY MENU
Buttons,
Submenus,
and Icons
Function(s)
QUIT
Save Data
Yes
No
Cancel
Touch the QUIT button to return to the Machine
Maintenance menu.
The Save Data message is displayed when the Quit button is
selected. At this location, you may:
Touch the Yes button to save your entries before returning to
the Machine Maintenance menu.
Touch the No button to return to the Machine Maintenance
menu without saving entries and changes you may have
made at the Machine Setup Entry menu.
Touch the Cancel button to cancel your "Quit" selection,
permitting you to continue to display the Machine Setup
Entry menu.
Select Chucks
If one chuck fails and is rendered inoperable, or to speed up
chuck alignment, touch the desired (right or left) chuck In
Use to continue single-chuck operation.
For a description, see the document entitled “Single-Chuck
Grinding on the 7AF Wafer Grinder.”
Variable
Label List
Box
Touch the scroll bar at the right of the Variable Label List
box to scroll down the list and locate the desired variable.
Touch the desired label to select it. The selected variable
label will now change to a highlighted display.
The selected calibration variable's number, label, and
present value are displayed in the Calibration Parameters
box, located at the left of the Variable Label List box.
