200MM WAFER GRINDER
MINOR FLAT SENSOR ASSEMBLY
1:1
1
1
D
A
265679A1
265679
MAY
6-22-04
7AF
MAY
6-22-04
WEIGHT:
6-22-04 A MAY INITIAL RELEASE C'11504
NOTES:
1. REFERENCE 224039A1 FOR AMPLIFIER LOCATION.
2. REPLACE ORIGINAL SCREWS ONE AT A TIME, PARTS ARE SPRING-LOADED.
3. PARTS NOT SHOWN:
104913 CABLE,22GA/2COND PVC BLK
220227 MDUL,INTERFACE, REFERENCE 224035A1
236177 WIRE,20GA,TEFLON JKT,BLU
240062 WIRE,AWG20,TEFLON JKT,BROWN
241994 MDUL,OUTPUT,DIGITAL,DC, REFERENCE 224035A1
