Series 2600B System SourceMeter® instrument Reference Manual Section 14: Model 2400 emulation
2600BS-901-01 Rev. F/August 2021 14-15
:ROUTe:TERMinals FRONt|REAR
The instrument accepts the command and ignores it.
The instrument always returns REAR.
[:SENSe[1]]:CURRent[:DC]:PROTection:RSYNchronize <Bool>
The measurement range only tracks the limit range when the output is on.
[:SENSe[1]]:FUNCtion:OFF:ALL
Readings are not made when all the functions are turned off.
[:SENSe[1]]:RESistance:MODE MANual|AUTO
Only MANual is supported. The instrument generates an error if AUTO is selected.
[:SENSe[1]]:RESistance:RANGe:AUTO <Bool>
The instrument ignores this command. Resistance auto range is always OFF.
[:SENSe[1]]:VOLTage[:DC]:PROTection:RSYNchronize <Bool>
The measurement range only tracks the limit range when the output is on.
:SOURce[1]:CLEar:AUTO:MODE ALWays|TCOunt
Only ALWays is supported. The instrument generates an error if TCOunt is selected.
:SOURce[1]:DELay:AUTO <Bool>
This setting is not supported with source memory sweeps. Source memory sweeps do not use automatic delays.
:SOURce[1]:FUNCtion:SHAPe DC|PULSe
This setting is not supported with source memory sweeps. Source memory sweeps always use dc.
:SOURce[1]:SWEep:RANGing BEST|AUTO|FIXed
When this setting is set to AUTO, a sweep leaves the corresponding source ranging set to AUTO. This is done each
time the sweep is run.
The 2499-DIGIO option is not supported. (16-bit size is not supported.)
