Section 14: Model 2400 emulation Series 2600B System SourceMeter® instrument Reference Manual
14-16 2600BS-901-01 Rev. F/August 2021
:SYSTem:AZERo:CACHing:NPLCycles?
:SYSTem:AZERo:CACHing:REFResh
This command is accepted and ignored. Causes no action or response.
:SYSTem:AZERo:CACHing:RESet
This command is accepted and ignored. Causes no action or response.
:SYSTem:AZERo:CACHing[:STATe] <Bool>
This command is accepted and ignored. The setting is always ON.
:SYSTem:AZERo:CACHing[:STATe]?
:SYSTem:AZERo[:STATe] <Bool>
When AZERO state is set to ON, reference and zero measurements are automatically made when they are out of
date. If this happens, the time to make a measurement increases. This can cause sweep timing to be irregular when
compared to a Model 2400 as the Model 2400 takes longer on every measurement.
:SYSTem:POSetup RST|PRESet|SAV0|SAV1|SAV2|SAV3|SAV4
SYSTem:POSetup command is accepted but has no effect, *SAV and *RCL are not supported.
:ARM[:SEQuence[1]][:LAYer[1]][:TCONfigure][:ASYNchronous]:ILINe 1|2|3|4
The instrument does not allow the same TLink line to be used for an input trigger and an output trigger simultaneously.
Also, it does not allow the same TLink line to be used as an input trigger for both the arm and trigger layer
simultaneously. The instrument generates an error when attempting to leave the idle layer if these conditions are
violated. The reset default for the arm layer input line (ARM:ILINe) is 1.
:ARM[:SEQuence[1]][:LAYer[1]][:TCONfigure][:ASYNchronous]:OLINe 1|2|3|4
The instrument does not allow the same TLink line to be used for an input trigger and an output trigger simultaneously.
The instrument generates an error when attempting to leave the idle layer if this condition is violated. The reset default
value for the arm layer output line (ARM:OLINe) is 3.
:TRIGger[:SEQuence[1]][:TCONfigure][:ASYNchronous]:ILINe 1|2|3|4
The instrument does not allow the same TLink line to be used for an input trigger and an output trigger simultaneously
nor does it allow the same TLink line to be used as an input trigger for both the arm and trigger layer simultaneously.
The instrument generates an error when attempting leave the idle layer if these conditions are violated. The reset
default for the trigger layer input line (TRIGger:ILINe) is 2.
:TRIGger[:SEQuence[1]][:TCONfigure][:ASYNchronous]:INPut SOURce|DELay|SENSe|NONE
Only one of these options may be selected at a time.
:TRIGger[:SEQuence[1]][:TCONfigure][:ASYNchronous]:OLINe 1|2|3|4
The instrument does not allow the same TLink line to be used for an input trigger and an output trigger simultaneously.
The instrument generates an error when attempting to leave the idle layer if this condition is violated. The reset default
for the trigger layer output line (TRIGger:OLINe) is 4.
