Toptech Systems MultiLoad II User Manual

Chapter 9 – Weights & Measures
283
Firmware Version 3/4.31.37
Table
Description
ASTM1250-
1980 Table
54AG Germany
This table provides CTL factors for correcting volumes of crude oil at observed
temperatures to the volume at 15 C. Use this table if the following conditions exist.
 The liquid is crude oil
 Density at 15 C is known
 Reference Temperature is 15 C
After selecting this table, enter the Density of the liquid at 15 C. The valid range of Density
is from 610-1075 kg/m3. Test temperatures can be entered on this screen that will calculate
a CTL based on the test temperature and the Density. The test temperature and Calculated
CTL are for informational purposes and will not be used in calculations during operations.
Density
Temperature
(610,5 to 778,5)
(779,0 to 824,0)
(824,5 to 1 075,0)
−18 to 95
−18 to 125
−18 to 150
ASTM1250-
1980 Table
54BG Germany
This table provides CTL factors for correcting volumes of gasolines at observed
temperatures to the volume at 15 C. Use this table if the following conditions exist.
 The liquid is a refined product
 Density at 15 C is known
 Reference Temperature is 15 C
After selecting this table, enter the Density of the liquid at 15 C. The valid range of Density
is from 600-1200 kg/m3. Test temperatures can be entered on this screen that will calculate
a CTL based on the test temperature and the Density. The test temperature and Calculated
CTL are for informational purposes and will not be used in calculations during operations.
Density
Temperature
600,0 to 770,4
770,5 to 778,5
778,6 to 787,5
787,6 to 824,0
824,1 to 838,5
838,6 to 1 200,0
18 to 95
−18 to 95
−18 to 125
−18 to 125
−18 to 150
−18 to 150
ASTM1250-
1980 Table
54CG Germany
This table provides CTL factors for correcting volumes of petroleum liquids at observed
temperatures to the volume at 15 C. Use this table if the following conditions exist.
 The liquid is a refined product or crude oil
 Coefficient of Expansion @ 15 C is known
 Reference Temperature is 15 C
After selecting this table, enter the Coefficient of Thermal Expansion (alpha) of the liquid at
15 C. The valid range of alpha is from 0.000486-0.001674. The alpha will be entered as
486-1674, however. Test temperatures can be entered on this screen that will calculate a
CTL based on the test temperature and the alpha. The test temperature and Calculated
CTL are for informational purposes and will not be used in calculations during operations.
Expansion
Temperature
0,000 486 to 0,000 918
0,000 919 to 0,000 954
0,000 955 to 0,001 674
18 to 150
−18 to 125
−18 to 95
ASTM1250-
1980 Table
54DG Germany
This table provides CTL factors for correcting volumes of lube oils at observed temperatures
to the volume at 15 C. Use this table if the following conditions exist.
 The liquid is a lube oil
 Density @ 15 C is known
 Reference Temperature is 15 C
After selecting this table, enter the Density of the liquid at 15 C. The valid range of Density
is from 750-1164 kg/m3. Test temperatures can be entered on this screen that will calculate
a CTL based on the test temperature and the Density. The test temperature and Calculated
CTL are for informational purposes and will not be used in calculations during operations.
Density
Temperature
750,0 to 1 164,0
18 to 170
