Toptech Systems MultiLoad II User Manual

Chapter 9 – Weights & Measures
306
Firmware Version 3/4.31.37
Tb=Tbm
Db=Dbm
Nb=Nbm
Mb=Mbm
Where: Gb=Gross volume loaded for the blend
Tb=Temperature for the blend
Db=Density for the blend
Nb=Net volume loaded for the blend
Mb=Mass loaded for the blend
Ethanol meter (Meter Level) values are reported as:
Gem=M2 (value not to be used for trade)
Tem=T2 (value not to be used for trade)
Dem=D2 OR De
Nem=Gem*VCFe(Tem,Dem) (value not to be used for trade)
Mem=Nem * D2 OR Mem=Gem * Dem (value not to be used for trade)
Where: Gem=Gross volume loaded for the Ethanol Meter
M2=Gross volume reported by meter M2
Tem=Temperature for the Ethanol Meter
T2= Volume weighted average temperature reported by probe T2
Dem=Density for the Ethanol Meter
D2=Volume weighted average Density measured OR specified for meter M2
De=Density specified for the Ethanol component
Nem=Net volume loaded for the Ethanol Meter
VCFe=API Correction Table for Ethanol
Mem=Mass loaded for the Ethanol Meter
Ethanol product (Component Level) values are reported as:
Ge=Gem (value not to be used for trade)
Te=Tem (value not to be used for trade)
De=De’ OR Dem
Ne=Nem (value not to be used for trade)
Me=Mem (value not to be used for trade)
Where: Ge=Gross volume loaded for the Ethanol component
Te=Temperature for the Ethanol component
De=Density for the Ethanol component
De’=Density specified for the Ethanol component
Ne=Net volume loaded for the Ethanol component
Me=Mass loaded for the Ethanol component
Regular product (Component Level) values are reported as:
Gr=Gbm-Ge (value not to be used for trade)
Tr=((Tbm * Gbm) – (Te * Ge)) / Gr (value not to be used for trade)
Dr=Dr’ OR
Dr= ((Dbm * Gbm) – (De * Ge)) / Gr (value not to be used for trade)
Nr=Nbm-Ne (value not to be used for trade)
Mr=Mbm-Me (value not to be used for trade)
