Firmware Version 3/4.31.37
If selecting the View Menu the W&M log will appear:
The most recent entry will be displayed at the top of the screen. To view earlier entries, press the Next key to
scroll through the earlier entries.
Note: To quickly return to the most recent entry, press Exit and re-select the View option.
Printing the W&M Change Log - Select Print to have the log printed. A serial printer must be connected to Com
Port 2 of the MultiLoad II to print this log. Com Port 2 must be configured as “Print” on the Communication Setup
screen to print the W&M Change Log.
Each event will contain two lines of data. The first line will consist of the following:
1. Reference Number-Up to 1000 entries will be retained in the log. After 1000 entries have been logged, the
oldest entry will be dropped. No reference number will be repeated until 65,535 events have been entered in
the log.
2. Preset Identification-This field describes the preset (load arm) that is relevant to the event. This value will
always be 1 on MultiLoad II SMP. Example: Pre:01 indicates that an event has occurred relevant to load arm
#1. The numeric designation that follows the Pre prefix is an arbitrary designation made by the facility
engineer. This is established during system configuration.
3. Component or Meter Identification-This field will indicate that a component level change was made or that
a meter level change was made. Since a load arm can have multiple components (liquids) or meters
assigned to it, a numeric indicator will identify which of the load arm’s components or meters is referenced.
VIEW WEIGHTS & MEASURES CHANGE LOG
Ref:00003 Pre:01 Cmp:01 None ->TAB59E
Id:1 07/03/23 10:58 API CTL Table Name
Ref:00002 Pre:01 Mtr:01 DISABLD-> ENABLED
Id:1 07/03/23 10:56 Temperature Sensor
Ref:00001
Id:1 07/03/23 10:54 Has W&M Access
Next Prev Exit
