9980 Self-Propelled Peanut Combine Introduction
MAN141.rev1 08/05/16 ix
Specifications (NOTE: Dimensions shown are for a dump basket equipped
combine.)
Dimension
Combine 318 (808) 203 (516) 174 (442) 32,000 (14,550)
Shipping 318 (808) 144 (366) 140 (355) 28,300 (12,800)
6/8 row header 227 (576) 52 (132) 51 (130) 4,100 (1,860)
8/10 row header 304 (772) 52 (132) 51 (130) 5,300 (2,400)
Basket (Dump) 203 (516) 96 (244) 77 (195) 4,000 (1,800)
Engine
Type .... Turbocharged, air-to-air after cooled
Cylinders ................................................... 6
Displacement ........................................ 9.0L
Horsepower ............... 320 HP @ 2200 RPM
High Speed Idle ......................... 2340 RPM*
*with Separator engaged ....... 2200 RPM**
**adjustable from 1950 RPM – 2200 RPM
while in harvesting mode
Mid Idle ....................................... 1690 RPM
Low Idle ....................................... 1200 RPM
Ground Drive
Type ................................ Hydraulic variable
Transmission ................................... 3-speed
Tires
Main drive (front) 800/65R32
30.5x32 16 ply
Steering (2-wheel drive) 18.4x26 10 ply
Steering (4-wheel drive) 18.4x26 10 ply
Capacities
Fuel tank .............................. 250 gal (950 L)
Cooling system ......................... 36 qt. (84 L)
Engine crankcase .................. 30 qt. (28.5 L)
Transmission ........................... 10 qt. (9.5 L)
Final Drives ............................... 9 qt. (8.5 L)
Engine gear case ..................... 17 qt. (16 L)
Hydraulic fluid ........................... 36 qt. (34 L)
Peanut bin ...................... 7,500 lb (3,400 kg)
Separation System
Type ................ Disc separator supplied by a
14in. (35 cm) cross induction
fan, 5 retractable spring
overhead separator cylinders
with stripper cylinder
Threshing System
Type .......... 10% variable speed engine, and
2 speed sprockets for first three cylinders,
variable speed for last two cylinders, 5
spring-toothed cylinders with stripper
cylinder, adjustable retention board, and
adjustable breast spring bars
Cylinder diameter ................... 30 in. (76 cm)
Section width ...................... 103 in. (259 cm)
Collection System
Auger diameter ....................... 12 in. (30 cm)
Pneumatic Conveyor
Area ......................... 84 sq. in. (0.054 sq. m)
Fan diameter .......................... 28 in. (71 cm)
