Amadas 9980 - Replace Rotary Screen Drive Belt

Engine Service 9980 Self-Propelled Peanut Combine
Replace Rotary Screen Drive
Belt
Change the rotary screen belt as needed. The
belt is routed as shown in the sketch.
A – Rotary screen
B – Belt
C – Idlers
D – Drive sheave
CAUTION
ALWAYS shut off engine, set the parking
brake, and remove the key before
performing maintenance.
232 09/04/15 MAN141
