Amadas 9980 - 9980 SP Combine with Dump bin

9980 Self-Propelled Peanut Combine Lubrication and Maintenance
9980 SP Combine with Dump
Bin
1. Using combine controls, lift the basket until
fully extended as shown in photo below
.
TURN OFF THE ENGINE AND REMOVE
THE KEY.
2. Locate the blue stop pin (top photo). The
pin was stored in the storage box behind
the passenger seat when the combine was
delivered from the factory.
3.
Insert the pin in place as shown in the
bottom two photos. You will need to step
into the combine opening to correctly insert
the pin. Make sure the pin is inserted
through both openings in
the hinge as
shown in the bottom photo.
Pin
Insert pin through both holes
MAN141 09/08/15 317
