9980 Self-Propelled Peanut Combine Engine Service
Engine Belt
There are three engine belts. They are routed
as shown below:
A – Rotary screen drive belt, screen side
B – Rotary screen drive belt, engine side
C – Cooling fan, air
conditioner, compressor
belt
MAN141 09/04/15 229
