9980 Self-Propelled Peanut Combine Diagnostic Codes
CAB: Control Unit CAB and Cab Power Module
Control Unit
SPN
FMI
Priority
Description
Cab air temperature sensor output (cc# 766) is out of range -
greater than 4.93 VDC.
Cab air temperature sensor output (cc# 766) is out of range -
less than 0.10 VDC.
Cab inlet air temperature sensor output (cc# 763) is out of
range - greater than 4.93 VDC.
Cab inlet air temperature sensor output (cc# 763) is out of
range -less than 0.10 VDC.
Control unit CAB has reset itself due to watchdog timer.
Start relay signal (cc# 107) is ON when commanded OFF
by control unit CAB.
Start relay signal (cc# 107) is OFF when commanded ON
by control unit CAB.
HVAC low pressure switch is open.
No Local CAN Bus messages are arriving.
Dimmer (cc# 549) is out of range -greater than 4.5 VDC.
Dimmer (cc# 549) is out of range -less than 0.5 VDC.
Cab backlighting (cc# 511) is ON when commanded
OFF by control unit CAB.
Cab backlighting (cc# 511) is OFF when commanded
ON by control unit CAB.
Unloading auger indicator (cc# 533) is ON when commanded
OFF by control unit CAB.
Unloading auger indicator (cc# 533) is OFF when commanded
ON by control unit CAB.
A row of switches in the armrest switch matrix is shorted
to voltage.
Armrest matrix connection status (cc# 928) voltage too low.
A column of switches in the armrest switch matrix is
shorted to ground.
Seat switch has remained closed for 8 continuous hours
of operation.
A row of switches in the multifunction control handle is
shorted to voltage.
A column of switches in the multifunction control handle is
shorted to ground.
Core temperature sensor output (cc# 764) is out of range
-greater than 4.93 VDC.
Core temperature sensor output (cc# 764) is out of range
-less than 0.10 VDC.
Temperature door position (cc# 774) is out of range when
fully closed -greater than 4.75 VDC.
Temperature door position (cc# 774) is out of range when
fully open -less than 0.25 VDC.
MAN141 09/08/15 363
