Amadas 9980 - Filters; Fresh Air Filter

Cab Climate Control 9980 Self-Propelled Peanut Combine
Filters
Fresh Air Filter
Clean this filter every 50 hours. In dusty
conditions, check every day and clean as
needed. To clean or check:
1. Loosen the knob and remove the access
cover (bottom photo).
2. Remove the wing nut (
bottom photo) and
pull out filter.
3. Clean filter and replace
; make sure wing
nut is securely in place.
4. Replace cover.
5. Replace and tighten knob.
6. Clean the recirculating filter (next page).
IMPORTANT! Do NOT overtighten the
knob.
Fresh air filter
Remove access
cover
Remove wing
nut and pull
out filter
134 09/04/15 MAN141
