9980 Self-Propelled Peanut Combine Engine Service
Rotary Screen
Opening the rotary screen door gives you
access to the rotary screen, oil cooler,
condenser, radiator, and charge air cooler.
To access these areas, pull the latches (top
and middle photos) open
open (bottom photo).
ALWAYS shut off the engine and remove
the key when performing maintenance.
screen
Door
MAN141 09/04/15 233
