Engine Service 9980 Self-Propelled Peanut Combine
Belts
For safety reasons, belts are enclosed behind
shields.
To open the drive belt shield (top photo),
remove the wing screws.
To open the rotary belt shield (middle photo),
open latches and swing the rotary shield door
open.
Do NOT operate combine without shield in
place. ALWAYS make sure engine is shut
off, parking brake set, and key out of
ignition before opening any shield.
228 09/04/15 MAN141
