Diagnostic Codes 9980 Self-Propelled Peanut Combine
LC1: Control Unit LC1 and Left Power Module 1
Control Unit
SPN
FMI Priority
LC1
523611
03
Service Alert
Left rear discharge light (cc# 566) is ON when commanded
OFF by left power module 1.
LC1
523611 05 Service Alert
Left rear discharge light (cc# 566) is open circuit.
LC1
523611 06
Service Alert
Left rear discharge light (cc# 566) is OFF when
commanded
ON by left power module 1.
LC1 523622 11
Service Alert
LPC1 power 5 (cc# 172) is less than 4.5 VDC at the left
power module 1 input.
LC1 523648
11
Service Alert
LPC1 power 4 (cc# 142) is less than 4.5 VDC at the left
power module 1 input.
LC1 523649 11
Service Alert
LPC1 power 3 (cc# 132) is less than 4.5 VDC at the left
power module 1 input.
LC1
523650 11
Service Alert
LPC1 power 2 (cc# 122) is less than 4.5 VDC at the left
power module 1 input.
LC1 523653
11 Service Alert
LPC1 power 1 (cc# 112) is less than 4.5 VDC at the left
power module 1 input.
LC1 523665
11 Service Alert
LC1 power 2 (cc# 152) is less than 4. VDC at the control
unit
LC1 input.
LC1
523666 11 Service Alert
LC1 power 1 (cc# 162) is less than 4. VDC at the control
unit
LC1 input.
LC1 523673 05
Service Alert
Control unit LC1 driver circuits are not grounded.
LC1 523919 03 Service Alert
Gullwing service lights (cc# 594) is ON when commanded
OFF by left power module 1.
LC1 523919 05 Service Alert
Gullwing service lights (cc# 594) is open circuit.
LC1 523919 06 Service Alert
Gullwing service lights (cc# 594) is OFF w hen commanded
ON by left power module 1.
374 09/08/15 MAN141
