9980 Self-Propelled Peanut Combine Cab Climate Control
Clean the panel only when it looks plugged.
1. Remove screws (A).
2.
Remove panel (B). (Air is brought in
through the left-hand side panel only. The
right-hand side panel does not provide cab
air.)
3. Clean with compressed air or water.
Remove fresh air filter to access precleaner
(A). The hole in floor under precleaner must
be kept open.
Turn off the engine, set parking brake,
and remove the key.
IMPORTANT! The precleaner is not
removable and must be cleaned without
removing from machine.
MAN141 09/04/15 133
