9980 Self-Propelled Peanut Combine Diagnostic Codes
LC2: Control Unit LC2 and Left Power Module 2
Control Unit SPN FMI Priority
Control unit LC2 has reset its elf due to watchdog timer.
No CAN Bus messages are arriving.
LC2 1231 12 Service Alert
Local CAN Bus message is not arriving on time or missing.
LC2 1554 03 Service Alert
Grain elevator
(Elevator Fan)
s peed (cc# 607) has no signal.
Sensor voltage is out of range high.
LC2 1554 04 Service Alert
Grain elevator (Elevator Fan) speed (cc# 607) has no signal.
Sensor voltage is out of range low.
LC2 1762 03 Service Alert
Hydro charge pressure (cc# 707) has voltage present
when the engine is running.
LC2 3509 03 Service Alert
LC2 s ensor supply 1 (cc# 273) is out of range -greater than
5.5 VDC.
LC2 3509 04 Service Alert
LC2 sensor supply 1 (cc# 273) is out of range -less than
4.5 VDC.
LC2 3597 04 Service Alert
LC2 PTC power (cc# 542) is out of range -less than 4.0 VDC.
LC2 523319 03 Service Alert
LC2 12V switched power (cc# 812) is ON when
commanded OFF.
LC2 523319 06 Service Alert
LC2 12V switched power (cc# 812) is OFF when
commanded ON.
Control Unit SPN FMI Priority
LC2 523511 03 Service Alert
Right two speed four wheel drive solenoid (cc# 201) is ON when
commanded OFF by left power m odule 2.
LC2 523511 05 Service Alert
Right two speed four wheel drive solenoid (cc# 201) is open circuit.
LC2 523511 06 Service Alert
Right two speed four wheel drive solenoid (cc# 201) is OFF when
commanded ON by left power module 2.
LC2 523512 03 Service Alert
Left two speed four w heel drive solenoid (cc# 204) is ON when
commanded OFF by left power m odule 2.
LC2 523512 05 Service Alert
Left two speed four w heel drive solenoid (cc# 204) is open circuit.
LC2 523512 06 Service Alert
Left two speed four w heel drive solenoid (cc# 204) is OFF when
commanded ON by left power module 2.
MAN141 09/08/15 379
