Lubrication and Maintenance 9980 Self-Propelled Peanut Combine
As Required
Clean off the top of the batteries and check
the level in each cell. Fill to the bottom of
the filler neck with distilled water.
Service the primary filter of the air cleaner
element only when shown by the warning
light.
a. Check the pre-cleaner for plugging.
b. Check for leaks and collapse of
aspirator tube.
c. Replace safety element if plugged. (air
filter Part # AH212295)
Service recirculating filter (part #
H220870):
a. Remove tray; reach in and lift out filter.
b. Clean or replace filter.
c. Replace filter in same position as when
removed.
Turn the knob on the cab fresh air filter
and pull out the door with the dirt tray.
Clean or replace filter. Replace filter in
same position as when removed (part #
336 09/08/15 MAN141
